Festo One-way flow regulator VFOE-LE-T-M5-Q4, 8068723
VFOE-LE-T-M5-Q4, Festo One-way flow control valve. Barely thicker than a tube and just as lightweight. Low-cost solution for standard applications, Simple and reliable adjustment of pneumatic cylinder speed
This product has been added to 1 people'scarts.
Not sure if this is the right product for you? Don't hesistate to contact us directly.
Fast Shipping
Our team work to ensure your orders are shipped as fast as possible at affordable shipping prices.
All Your Fluid Power Needs
We aim to offer a wide range of product ranges, sizes and variations to fit all industry needs.
Trusted Brands
We are endorsed suppliers for trusted brands such as PCL, John Guest, Festo, WPL Pro & Tygris.
Description
VFOE-LE-T-M5-Q4, 8068723, Festo One-way flow control valve can be mounted directly on the drive. Low-cost solution for standard applications. Simple and reliable adjustment of pneumatic cylinder speed. Extremely easy assembly, Fast commissioning, Compact dimensions. More control valves.
Valve function, Supply air one-way flow control function
Standard nominal flow rate in flow control direction, 85 l/min
Width across flats, 9 mm
Pneumatic connection, port 1, QS-4
Adjustment component, Rotary knob with detent
One-way flow control valves from Festo provide optimum performance at all times and in every situation. Barely thicker than a tube and just as lightweight, the one-way flow control valve can be mounted directly on the drive.
One-way flow control valves
One-way flow control valves only restrict the flow in one direction; in the reverse direction the full flow is freely available. One-way flow control valves are used, among other things, to set the speed of pneumatic cylinders.
Festo one-way flow control valves for pneumatic actuators
The piston speed of both advancing and retracting pneumatic cylinders can be regulated using one-way flow control valves from Festo. This is achieved by reducing the flow rate in the exhaust air or supply air direction. The non-return function works in the opposite direction.
Additional information
| Weight | 0.006 kg |
|---|---|
| Festo Series | VFOE |
